DM-SE Series 3D Camera

Industrial high-precision 3D camera

The DM-SE camera is a cost-effective and smart RGBD camera designed for industrial applications. Powered by a high-performance iToF sensor based on SONY DepthSense® technology platform, it provides reliable depth imaging. The integrated interface is ideal for embedded platforms or space-constrained installations. Additionally, it offers standardized tutorials for secondary development , enabling users to develop and deploy 3D vision algorithms efficiently. The DM-SE camera is well-suited for many scenarios, including Logistics Depalletizing, Collision Avoidance, Pallet Recognition, Safety Area Protection, Smart Construction Sites, Agricultural Harvesting, Smart Wheelchairs, Intelligent Security and People Flow Statistics.

Features

Product Number		LWP-D345-I	LWP-D345C-I	LWP-D345W-I
Operating Principle		ToF
Sensor		Sony IMX570
Laser		940nm VCSEL*2
Working Distance		0.2m~10m
Ranging Accuracy		±3mm+0.25%*depth
ToF Field of View（H×V）		70°（±2）*50°（±2）		103°（±2）*81°（±2）
ToF Resolution		640*480 dpi
RGB Resolution		/	1600*1200 dpi	/
Resolution		Standard mode: Max 15fps
Human Eye Safety		Class 1
Function	HDR Function	Normal HDR or High-precision HDR
	Exposure Time	0-4000μs Exposure time adjustment
	Filters	Support multiple filter settings including spatial, temporal, confidence, and fly point filters
	Output Data Type	Depth、IR、PointCloud、IMU	Depth、IR、PointCloud、IMU、RGB（YUV）	Depth、IR、PointCloud、IMU
Interface	Power Supply	DC12V~24V
	Power Consumption	15W
	Network Interface	RJ45
	Power and I/O Interface	8-pin Open
Physics	Dimensions （L×W×H)	108mm×39mm×60mm
	Weight	410g
	Operating Temperature	-30℃~65℃
	Operating Temperature	-40℃~85℃
	Protection Level	IP67
Supported System		Above Windows10 / above Ubuntu 20.04 / Ros

DM-SE Series 3D Camera

Industrial high-precision 3D camera

Features

Applications

Depalletizing of Soft Packages

Filling-port Position

Pallet Recognition

People Flow Statistics

Safety Area Protection

Sorting and Gripping
